Electrical characteristics

STM32F765xx STM32F767xx STM32F768Ax STM32F769xx

202/255

DocID029041 Rev 4

Synchronous waveforms and timings

Figure 65 through Figure 68 represent synchronous waveforms and Table 108 through

Table 111 provide the corresponding timings. The results shown in these tables are obtained

with the following FMC configuration:

•

BurstAccessMode = FMC_BurstAccessMode_Enable;

•

MemoryType = FMC_MemoryType_CRAM;

•

WriteBurst = FMC_WriteBurst_Enable;

•

CLKDivision = 1;

•

DataLatency = 1 for NOR Flash; DataLatency = 0 for PSRAM

•

CL = 30 pF on data and address lines. CL = 10 pF on FMC_CLK unless otherwise

specified.

In all the timing tables, the THCLK is the HCLK clock period.

–

For 2.7 V≤ VDD≤ 3.6 V, maximum FMC_CLK = 100 MHz at CL=20 pF or 90 MHz at

CL=30 pF (on FMC_CLK).

–

For 1.71 V≤ VDD<2.7 V, maximum FMC_CLK = 70 MHz at CL=10 pF (on FMC_CLK).

1. Guaranteed by characterization results.

Table 107. Asynchronous multiplexed PSRAM/NOR write-NWAIT timings(1)

1. Guaranteed by characterization results.

Symbol

Parameter

Min

Max

Unit

tw(NE)

FMC_NE low time

9THCLK – 1

9THCLK + 1

tw(NWE)

FMC_NWE low time

7THCLK – 0.5 7THCLK + 0.5

tsu(NWAIT_NE)

FMC_NWAIT valid before FMC_NEx high

6THCLK + 2

th(NE_NWAIT)

FMC_NEx hold time after FMC_NWAIT

invalid

4THCLK – 1
