background image
https://www.phoenixcontact.com/us/products/2902955
09/06/2016   Page 3 / 11
Relay Module - PLC-RSC- 24DC/21 ATEX - 2902955
Technical data
General
Standards/regulations
IEC 60664
EN 50178
IEC 62103
EN 60079-0
EN 60079-15
Degree of pollution
2
2 (EN 60664-1)
Overvoltage category
III
ATEX
DEMKO 11 ATEX 1111531U
 II 3 G Ex nA nC IIC Gc
UL, USA
Class I, Zone 2, AEx nA nC IIC T6
UL, USA/Canada
Class I, Div. 2, Groups A, B, C, D
UL, Canada
Class I, Zone 2, Ex nA nC IIC Gc T6 X
Mounting position
any
Assembly instructions
In rows with zero spacing
Connection data input side
Connection name
Coil side
Connection method
Screw connection
Stripping length
8 mm
Screw thread
M3
Conductor cross section solid
0.14 mm² ... 2.5 mm²
Conductor cross section flexible
0.14 mm² ... 2.5 mm²
Conductor cross section AWG
26 ... 14
Connection data output side
Connection name
Contact side
Connection method
Screw connection
Stripping length
8 mm
Screw thread
M3
Conductor cross section solid
0.14 mm² ... 2.5 mm²
Conductor cross section flexible
0.14 mm² ... 2.5 mm²
Conductor cross section AWG
26 ... 14
Standards and Regulations
Designation
Standards/regulations
Standards/regulations
IEC 60664
EN 50178
IEC 62103
