background image
https://www.phoenixcontact.com/us/products/2902955
09/06/2016   Page 4 / 11
Relay Module - PLC-RSC- 24DC/21 ATEX - 2902955
Technical data
Standards and Regulations
EN 60079-0
EN 60079-15
Degree of pollution
2
Overvoltage category
III
Flammability rating according to UL 94
V0
Conformance
CE-compliant
ATEX
DEMKO 11 ATEX 1111531U
 II 3 G Ex nA nC IIC Gc
UL, USA
Class I, Zone 2, AEx nA nC IIC T6
UL, USA/Canada
Class I, Div. 2, Groups A, B, C, D
UL, Canada
Class I, Zone 2, Ex nA nC IIC Gc T6 X
Drawings
Circuit diagram
A1
A2
11
14
12
Classifications
eCl@ss
eCl@ss 4.0
27371104
eCl@ss 4.1
27371104
eCl@ss 5.0
27371601
eCl@ss 5.1
27371601
eCl@ss 6.0
27371601
eCl@ss 7.0
27371601
eCl@ss 8.0
27371601
eCl@ss 9.0
27371601
ETIM
ETIM 2.0
EC001437
ETIM 3.0
EC001437
