STSPIN820 Datasheet(PDF) 7 Page - STMicroelectronics

Part # STSPIN820
Description  Advanced 256 microsteps integrated motor driver with step-clock and direction interface
PDF  29 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  STMICROELECTRONICS [STMicroelectronics]
Direct Link  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

STSPIN820 Datasheet(HTML) 7 Page - STMicroelectronics

Back Button STSPIN820 Datasheet HTML 3Page - STMicroelectronics STSPIN820 Datasheet HTML 4Page - STMicroelectronics STSPIN820 Datasheet HTML 5Page - STMicroelectronics STSPIN820 Datasheet HTML 6Page - STMicroelectronics STSPIN820 Datasheet HTML 7Page - STMicroelectronics STSPIN820 Datasheet HTML 8Page - STMicroelectronics STSPIN820 Datasheet HTML 9Page - STMicroelectronics STSPIN820 Datasheet HTML 10Page - STMicroelectronics STSPIN820 Datasheet HTML 11Page - STMicroelectronics Next Button
Zoom Inzoom in Zoom Outzoom out
 7 / 29 page
background image
DocID031065 Rev 2
7/29
STSPIN820
Electrical data
29
2.4
ESD protection ratings
Table 4. ESD protection ratings
Symbol
Parameter
Conditions
Class Value
Unit
HBM
Human body model
Conforming to ANSI/ESDA/JEDEC JS001
H2
2
kV
CDM
Charge device model
Conforming to ANSI/ESDA/JEDEC JS002
All pins
C2a
500
V
Conforming to ANSI/ESDA/JEDEC JS002
Corner pins only (1, 6, 7, 12, 13, 18, 19, 24)
-750
V
MM
Machine model
Conforming to EIA/JESD22-A115-C
NC
200
V
