background image
MODEL: R8-NM1
R8-NM1 SPECIFICATIONS
ES-9722 Rev.5 Page 8/10
http://www.m-system.co.jp/
■ DISCRETE DATA
0
15
Input 1 (Output 1)
Input 2 (Output 2)
Input 3 (Output 3)
:
Input 16 (Output 16)
0: OFF
1: ON
For I/O mixed modules shown below, interlock status is assigned to input 1 (to 3) in addition to output 1 to 16.
(Available with R8-NM1 Version 1.04 or later)
R8-DCM16ALZ
Input 1
Global interlock
R8-DCM16ALK
Input 1
Global interlock
Input 2
Individual interlock 1
Input 3
Individual interlock 2
R8-DCM16ALH
Input 1
Global interlock
Input 2
Partial interlock 1
Input 3
Partial interlock 2
