FT900

/1/2/3 Revision C Embedded Microcontroller Datasheet

Version 1.0

Document No.: BRT_000172 Clearance No.: BRT#087

3.3

Pin Description

No.

Name

Type

Description

CAN1_TXD/CAM_D0/GPIO17

I/O

GPIO17 input/output. (By default is GPIO input, internal pull-low)

Camera data 0 input.

CAN1 transmitter output. [1]

CAN1_RXD/GPIO18

I/O

GPIO18 input/output. (By default is GPIO input, internal pull-low)

CAN1 receiver input.[1]

SD_CLK/GPIO19

I/O

GPIO19 input/output. (By default is GPIO input, internal pull-low)

SD card serial clock output.

SD_CMD/GPIO20

I/O

GPIO20 input/output. (By default is GPIO input, internal pull-low)

SD card command signal input/output.

SD_DATA3/GPIO21

I/O

GPIO21 input/output. (By default is GPIO input, internal pull-low)

SD card data bus line 3 input/output.

SD_DATA2/GPIO22

I/O

GPIO22 input/output. (By default is GPIO input, internal pull-low)

SD card data bus line 2 input/output.

SD_DATA1/GPIO23

I/O

GPIO23 input/output. (By default is GPIO input, internal pull-low)

SD card data bus line 1 input/output.

SD_DATA0/GPIO24

I/O

GPIO24 input/output. (By default is GPIO input, internal pull-low)

SD card data bus line 0 input/output.

SD_CD/GPIO25

I/O

GPIO25 input/output. (By default is GPIO input, internal pull-low)

SD card detect input.

SD_WP/GPIO26

I/O

GPIO26 input/output. (By default is GPIO input, internal pull-low)

SD card write protection input.

SPIM_CLK/GPIO27

I/O

GPIO27 input/output. (By default is GPIO input, internal pull-low)

Serial clock output for SPI master.

SPIM_SS0/GPIO28

I/O

GPIO28 input/output. (By default is GPIO input, internal pull-low)

Slave select 0 output for SPI master.

SPIM_MOSI/GPIO29

I/O

GPIO29 input/output. (By default is GPIO input, internal pull-low)

Master out slave in for SPI master.

Data line 0 input/output for SPI master dual & quad mode.

SPIM_MISO/GPIO30

I/O

GPIO30 input/output. (By default is GPIO input, internal pull-low)

Master in slave out for SPI master.

Data line 1 input/output for SPI master dual & quad mode.

SPIM_IO2/GPIO31

I/O

GPIO31 input/output. (By default is GPIO input, internal pull-low)

Data line 2 input/output for SPI master quad mode.

SPIM_IO3/GPIO32

I/O

GPIO32 input/output. (By default is GPIO input, internal pull-low)

Data line 3 input/output for SPI master quad mode.
