1.2

Fibre Cabling

1.2.5

Volition™ Patch Cable

Single-mode 9/125/250µm

Description

Patch cable, Single-mode 9/125/250µm

Factory made VF-45 Duplex patch cables in various lengths are

used for patching between sockets or for making the connection to

transceivers on the workstation, hub or switch. Hybrid cables to

connect ST, SC, LC and MTRJ interfaces are also available.

Other Hybrids available upon request.

Note: During 2005, the patch cables will be changed to a universal

type, which is both riser and LSZH rated. Reference numbers will

change. For example: from VOL-V9L1 to VOL-V9L/R1

Highlights:

• Duplex connection

• Factory made VF-45 duplex patch cables in various lengths

• Automatic dust protection protects fibres in unmated

condition

• Tested to TIA/EIA and IEC performance requirements

• Patchcords made with 3M’s innovative coated fibre, GGP,

minimum bend radius 25mm

Type/Order Text

Ref.-No.

VF-45-Connector to VF-45-Connector, 9/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-V9L1

1,5 m

VOL-V9L1,5

VOL-V9L2

VOL-V9L3

VOL-V9L5

VOL-V9L8

15 m

VOL-V9L15

30 m

VOL-V9L30

VF-45-Connector to ST-Connector, 9/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-T9L1

1,5 m

VOL-T9L1,5

VOL-T9L2

VOL-T9L3

VOL-T9L5

VOL-T9L8

15 m

VOL-T9L15

30 m

VOL-T9L30

VF-45-Connector to SC-Connector, 9/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-C9L1

1,5 m

VOL-C9L1,5

VOL-C9L2

VOL-C9L3

VOL-C9L5

VOL-C9L8

15 m

VOL-C9L15

30 m

VOL-C9L30

Other types upon request

VF-45-Connector to MTRJ-Connector, 9/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-M9L1

VOL-M9L2

VOL-M9L3

VOL-M9L5

VOL-M9L8

10 m

VOL-M9L10
