1.3

Networking Hardware

1.3.2

Volition™ Network Interface Cards

Description

Type/Order text

Ref.-No.

Network Interface Cards

The Volition fibre based PCI network interface card supports Fast

Ethernet protocols, 100 Mb/s. The Nic supports most major oper-

ating systems and offer high performance with reliable operation in

todays demanding networks.

The 100 Mb/s card operates at either full or half duplex. The VOL-

N100VF+TX card has a VF-45 optical port plus an RJ45 copper

port with wake on LAN feature and therefore offers full flexibility for

migration paths.

Highlights:

•IEEE 802.3/802.3u and 802.3z compliant

• 32 bit bus mastering (10 and 100Mb/s cards)

• most common operating systems supported

• dual port copper/fibre 100Mb/s NIC available for easy

network migration (VOL-N100VF + TX)

Volition™ Network Interface Card

VOL-N100VF+TX, 2Port, 10/100MB NIC, PCI Bus

VOL-N100VF+TX

1 Port 10/100 Base-TX Volition™ RJ45,

1 Port 100 Base-FX with Volition™ VF-45, 1300nm

PU: 1 pc

MOQ: 1

Available until Q3/2005

VOL-N100VF+TX-R, 2Port, 10/100MB NIC, PCI Bus

VOL-N100VF+TX-R

1 Port 10/100 Base-TX Volition™ RJ45,

1 Port 100 Base-FX with Volition™ VF-45, 1300nm

PU: 1 pc

MOQ: 1

Available from Q4/2005
