PowerPC 440SP Embedded Processor
16
AMCC Proprietary
Revision 1.23 - Sept 26, 2006
Data Sheet
Figure 3. 29mm, 783-Ball FC-PBGA Core Package
Top View
Bottom View
Note: All dimensions are in mm.
01 03 05 07 09 11 13 15 17 19
02 04 06 08 10 12 14 16 18
21 23
20 22 24
A
B
C
D
E
F
G
H
J
K
L
M
AA
N
P
R
T
U
V
W
Y
AB
AC
AD
29.0 ± 0.2
1.00 TYP
29.0 ± 0.2
3.27 MAX
0.4 MIN
0.6 ± 0.1 SOLDERBALL x 783
25
26
27
28
AF
AE
AG
AH
A1 Corner
24
AD
A
1
PPC440SP
xpCfffC
Part Number
AAAAAAAA
Lot Number
®
