CC1050

SWRS044

Page 33 of 40

PA_POW Register (0Bh)

NAME

Default

value

Active

Description

PA_POW[7:4]

PA_HIGHPOWER[3:0]

0000

Control of output power in high power array.

Should be 0000 in PD mode . See

Table

3 page 25 for details.

PA_POW[3:0]

PA_LOWPOWER[3:0]

1111

Control of output power in low power array

Should be 0000 in PD mode. See

Table

3 page 25 for details.

PLL Register (0Ch)

NAME

Default

value

Active

Description

PLL[7]

EXT_FILTER

1 : External loop filter

0 : Internal loop filter

1-to-0 transition samples F_COMP

comparator when BREAK_LOOP=1

(TEST3)

PLL[6:3]

REFDIV[3:0]

0010

Reference divider

0000 : Not allowed

0001 : Not allowed

0010 : Divide by 2

0011 : Divide by 3

...........

1111 : Divide by 15

PLL[2]

ALARM_DISABLE

0 : Alarm function enabled

1 : Alarm function disabled

PLL[1]

ALARM_H

Status bit for tuning voltage out of range

(too close to VDD)

PLL[0]

ALARM_L

Status bit for tuning voltage out of range

(too close to GND)

Not Recommended for New Designs
