CC1050
SWRS044
Page 6 of 40
Parameter
Min.
Typ.
Max.
Unit
Condition / Note
Serial interface (PCLK, PDATA and
PALE) timing specification
See Table 2 page 13
Current Consumption
Power Down mode
0.2
1
µA
Oscillator core off
Current Consumption,
transmit mode 433/868 MHz:
P=0.01mW (-20dBm)
P=0.3mW (-5dBm)
P=1mW (0dBm)
P=3mW (5dBm)
P=6mW (8dBm)
P=16mW (12dBm)
5.5/8.0
7.3/10.0
9.1/14.2
13.3/17.7
15.9/24.9
23.3/NA
mA
mA
mA
mA
mA
mA
The output power is delivered to a
50
Ω load
Current Consumption, crystal osc.
Current Consumption, crystal osc.
and bias
Current Consumption, crystal osc.,
bias and synthesiser
30
80
105
400
4.0
5.5
µA
µA
µA
µA
mA
mA
3-8 MHz, 16 pF load
9-14 MHz, 12 pF load
14-16 MHz, 16 pF load
< 500 MHz
> 500 MHz
Not Recommended for New Designs
