2

GENERAL SPECIFICATIONS (CON'T)

FUNCTION SPECIFICATIONS

USB PORT SPECIFICATIONS

ETHERNET PORT 1 SPECIFICATIONS

ETHERNET PORT 2 SPECIFICATIONS

Insulation Resistance

Between power and FE terminals:

100MΩ or higher (500V DC megger)

Between transistor output and FE terminals:

100MΩ or higher (500V DC megger)

Between power and input terminals:

100MΩ or higher (500V DC megger)

Between power and relay output terminals: 100 MΩ

or higher (500V DC megger)

Between input and relay output terminals:

100MΩ or higher (500V DC megger)

Between input and FE terminals:

100MΩ or higher (500V DC megger)

Between relay output and FE terminals:

100MΩ or higher (500V DC megger)

Between power and transistor output terminals:

100 MΩ or higher (500V DC megger)

Between input and transistor output terminals:

100 MΩ or higher (500V DC megger)

Noise Resistance

AC/DC power terminals: 1kV, 50ns to 1μs

I/O terminals (coupling clamp): 1.5kV, 50ns to 1μs coupling adapter

Vibration Resistance

5 to 8.4Hz amplitude 3.5mm

8.4 to 150Hz acceleration 9.8m/s2 (1G), 2 hours per axis on each of three mutually perpendicular axes

(IEC 61131-2)

Shock Resistance

147m/s2 (15G), 11ms duration, 3 shocks per axis on three mutually perpendicular axes

Degree of Protection

IP20 (IEC 60529)

Power Supply Wire

UL1007 AWG24-16, UL2464 AWG24-16, UL1015 AWG20-16

Grounding Wire

UL1007 AWG16

Ground

D-type ground (Class 3 ground)

Mounting

DIN rail or panel mounting

Weight (approx.)

FC6A-D16R1CEE: 290g

FC6A-D16P1CEE: 275g

FC6A-D16K1CEE: 275g

FC6A-D32P3CEE: 255g

FC6A-D32K3CEE: 255g

Part No.

FC6A–D16R1CEE

FC6A–D16P1CEE (*4)

FC6A–D16K1CEE (*4)

FC6A–D32P3CEE (*4)

FC6A–D32K3CEE (*4)

Control System

Stored program system

Instruction Words

Basic

42

Advanced

130

Program Capacity (*1)

800KB (100,000 steps)

User Program Storage

Serial Flash Memory (100,000 times rewritable)

Processing Time

Basic Instruction

21μs/1,000 steps

END Processing (*2)

1ms maximum

I/O Points

Input

8 points

16 points

Output

8 points

16 points

Expandable Modules

7 modules (*3)

Expandable I/O Points with Expansion Modules

224 points

Expandable Modules with Unibody Type Expansion

Modules

8 modules

Expandable I/O Points with Unibody Type Expansion

Modules

256 points

Expandable Modules with Separate Type Expansion

Modules (*5)

63 modules (separate type master: 1 module maximum, separate type slave: 10

modules maximum)

Expandable I/O Points with Separate Type Expansion

Modules (*5)

2,016 points

Internal Relay

15,400 points

Special Internal Relay

1,600 points

Shift Register

256 points

Data Register

60,000 points

Non-Retentive Data Register

200,000 points

Special Data Register

900 points

Counter

512 points

Timer (1ms, 10ms, 100ms,1s)

2,000 points

Clock

Clock accuracy: ±30 sec/month (typical) at 25°C

RAM Backup

Backup Data

Internal relay, shift register, counter, data register, timer, special data register,

special internal relay, clock data

Battery

Lithium primary battery (BR2032)

Battery Life

Approx. 4 years

Replaceability

Possible

Self-diagnostic Function

Keep data, user program sum check (serial flash memory), user program sum check

(RAM), timer/counter preset value sum check, user program syntax check, user

program execution check, WDT check,

user program write check, power failure, clock error, data ink connection check, I/O

bus initialization check

Input Filter

0 ms (without filter), 3 to 15ms (selectable in increments of 1ms)

I14, I15, I16, I17: 3ms

Catch Input/Interrupt Input

Six inputs

I0, I1, I3, I4, I6, I7 (Minimum turn on pulse width: 5μs max./Minimum turn off pulse

width: 5μs max.)

USB Type

USB mini-B

USB Standard

USB 2.0

Isolation

Not isolated from the internal

circuit

Communication Function

Maintenance communication to

PC

Communication Type

IEEE802.3 compliant

Communication Speed

10BASE-T, 100BASE-TX

Connector

RJ45

Cable

CAT.5STP

Maximum Cable Length

100m

Isolation

Pulse trans isolation

Communication

Function

Maintenance communication (server),

user communication (server/client),

user communication UDP, Modbus TCP

(server/client), Email, Web Server, PING,

SNTP, FTP server/client

Communication Type

IEEE802.3 compliant

Communication Speed

10BASE-T, 100BASE-TX

Connector

RJ45

Cable

CAT.5STP

Maximum Cable Length

100m

Isolation

Pulse trans isolation

Communication Function

Maintenance communication (server),

user communication (server/client),

user communication UDP, Modbus

TCP (server/client), PING
