Data Sheet

ADMV8809

SPECIFICATIONS

analog.com

Rev. A | 4 of 55

Table 1. Specifications (Continued)

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

INSERTION LOSS

Bypass Configuration

<1.5

Filter Band 1

6.2

Filter Band 2

4.7

Filter Band 3

4.5

Filter Band 4

RETURN LOSS

>10

DYNAMIC PERFORMANCE

Input Compression (P0.1dB)

Bypass Configuration

dBm

Filter Band 1

26.10

dBm

Filter Band 2

26.83

dBm

Filter Band 3

dBm

Filter Band 4

24.66

dBm

Input Third-Order Intercept (IP3)

Input power (PIN) = 10dBm per tone

Bypass Configuration

dBm

Filter Band 1

dBm

Filter Band 2

dBm

Filter Band 3

dBm

Filter Band 4

dBm

Group Delay

<5.4

Amplitude Switching Time

Typically <0.5

µs

To within ≤1dB of static insertion loss

Amplitude Settling Time

0.5

µs

To within ≤0.5dB of static insertion loss

Phase Settling Time

0.8

µs

To within ≤2° of static insertion phase

Drift Rate

Amplitude

Filter Band 1

0.01

dB/°C

HPF = LPF, State 4

Filter Band 2

0.01

dB/°C

HPF = LPF, State 4

Filter Band 3

0.01

dB/°C

HPF = LPF, State 4

Filter Band 4

0.01

dB/°C

HPF = LPF, State 4

Frequency

Filter Band 1

−68

ppm/°C

HPF = LPF, State 4

Filter Band 2

−65

ppm/°C

HPF = LPF, State 4

Filter Band 3

−99

ppm/°C

HPF = LPF, State 4

Filter Band 4

−105

ppm/°C

HPF = LPF, State 4

SUPPLY VOLTAGE

VSS

–2.6

–2.5

–2.4

VDD

3.2

3.3

3.4

SUPPLY CURRENT (STATIC)

Static

VSS Current (ISS)

µA

VDD Current (IDD)

700

µA

Dynamic

IDD

fSCLK/4

Where fSCLK is the SCLK toggle frequency in MHz, for

example, continuous serial peripheral interface (SPI) writing

at 10MHz yields 2.5mA of dynamic IDD
