Data Sheet

ADMV8809

ABSOLUTE MAXIMUM RATINGS

analog.com

Rev. A | 7 of 55

Table 3. Absolute Maximum Ratings

Parameter

Rating

SUPPLY

VDD

–0.3V to +3.6V

VSS

–2.75V to +0.3V

Digital Control Inputs

Voltage

–0.3V to VDD + 0.3V

Current

2mA

Continuous RF Input Power

P0.1dB

Temperature

Operating Range

–40°C to +85°C

Storage Range

–55°C to +150°C

Junction to Maintain 1 Million Hours Mean Time

to Failure (MTTF)

135°C

Nominal Junction (Paddle Temperature

(TPADDLE) = 85°C)

90°C

Moisture Sensitivity Level (MSL) Rating

MSL3

Stresses at or above those listed under Absolute Maximum Ratings

may cause permanent damage to the product. This is a stress

rating only; functional operation of the product at these or any other

conditions above those indicated in the operational section of this

specification is not implied. Operation beyond the maximum operat-

ing conditions for extended periods may affect product reliability.

ELECTROSTATIC DISCHARGE (ESD) RATINGS

The following ESD information is provided for handling of ESD-sen-

sitive devices in an ESD protected area only.

Human body model (HBM) per ANSI/ESDA/JEDEC JS-001-2010.

Field induced charged device model (FICDM) per ANSI/ESDA/JE-

DEC JS-002.

ESD Ratings for ADMV8809

Table 4. ADMV8809, 52-Terminal LGA

ESD Model

Withstand Threshold (V)

Class

HBM

RFx Pins

750

Supply and Digital Pins

1500

FICDM

250

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Charged

devices and circuit boards can discharge without detection.

Although this product features patented or proprietary protec-

tion circuitry, damage may occur on devices subjected to high

energy ESD. Therefore, proper ESD precautions should be

taken to avoid performance degradation or loss of functionality.
