ADRF5420

OUTLINE DIMENSIONS

Legal Terms and Conditions

Information furnished by Analog Devices is believed to be accurate and reliable "as is". However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of

patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or

patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners. All Analog Devices products contained herein are subject to release and

availability.

analog.com

Rev. 0 | 14 of 14

Package Drawing Option

Package Type

Package Description

CD-30-3

BUMPED_CHIP

38-Ball Bumped Bare Die Sales

For the latest package outline information and land patterns (footprints), go to Package Index.

ORDERING GUIDE

Model1

Temperature Range

Package Description

Packaging Quantity

Package Option

ADRF5420BCDZ

−40°C to +105°C

30-Ball Bumped Bare Die Sales [BUMPED_CHIP]

Cut-Tape, 1 to 500

CD-30-3

ADRF5420BCDZ-R7

−40°C to +105°C

30-Ball Bumped Bare Die Sales [BUMPED_CHIP]

Reel, 500

CD-30-3

1 Z = RoHS-Compliant Part.
