PROTEC TA PLUS MCB DIS TR IBUTION B OA R D 2 5 0A

—

Protecta Plus

Order Codes

Description

Order codes

125A MID Approved c/w pulse output

EPP-METMOD125A

125A MID Approved c/w pulse output & Modbus ( RS485 )

EPP-METMOD125B

125A MID Approved c/w pulse output, Modbus ( RS485 ) Imp / Exp

EPP-METMOD125C

160A MID Approved c/w pulse output

EPP-METMOD160A

160A MID Approved c/w pulse output & Modbus ( RS485 )

EPP-METMOD160B

160A MID Approved c/w pulse output, Modbus ( RS485 ) Imp / Exp

EPP-METMOD160C

250A MID Approved c/w pulse output

EPP-METMOD250A

250A MID Approved c/w pulse output & Modbus ( RS485 )

EPP-METMOD250B

250A MID Approved c/w pulse output, Modbus ( RS485 ) Imp / Exp

EPP-METMOD250C

—

Incoming metering

Description

Order codes

125A 3P Switch incoming connection kit

EPP-1253P

125A 4P Switch incoming connection kit

EPP-1254P

100A 4P RCD incoming connection kit 30mA Type AC - Left side neutral

EPP-1004R

160A 3P Switch incoming connection kit

EPP-1603P

160A 4P Switch incoming connection kit

EPP-1604P

250A 3P Switch incoming connection kit

EPP-2503P

250A 4P Switch incoming connection kit

EPP-2504P

Pack contents: Incoming kit

• Copper connection kit and fittings

• Incoming device

• Cover plate

• Instruction leaflet

—

Incoming connection kit

Pack contents: Incoming metering

• 1 x Meter

• 1 x C.T Block

• 1 x Wiring Loom & DIN support

• Instruction leaflet

Please note as these kits allow for 4 to 24way

boards cutting and crimping of cables is required.
