IO bus interface description
STLS2F02
18/49
3.4.1
Single processor system connection
Figure 3.
STLS2F02 uniprocessor system connection
3.4.2
Multiprocessor system connections
Figure 4.
STLS2F02 multiprocessor system connections
PCI Dev
PCI Dev
PCI Dev
Loongson 2F
PCI Bus
PCI_REQ
PCI_GNT
Local Bus
Boot Rom
I/O
Chipset
Loongson 2F
PCI Bus
PCI_REQn
PCI_GNTn
PCI Bus
PCI_REQn
PCI_GNTn
