WI.232FHSS-25-R/ WI.232FHSS-250-R DATASHEET

Revision 1.1.0

4.1.25. User ID Mask[0] (regUSERIDMASK[0])

regNVUSERIDMASK[0] (0x1A)

regUSERIDMASK[0] (0x65)

R/W

Default User ID Mask[0]: 0xFF

When extended-user addressing is invoked, this register holds the least significant byte of the 32-bit user-

extended address mask and is used in conjunction with User ID Mask[3-1] to form the complete address

mask; when user addressing is invoked, this register holds the least significant byte of the 16-bit user

address mask and is used in conjunction with the User ID Mask[1] register to form the complete address

mask. For more information on the operation of addressing modes, please refer to the Addressing Modes

section of this document.

4.1.26. Destination GUID[3] (regDESTGUID[3])

regNVDESTGUID[3] (0x1D)

regDESTGUID[3] (0x68)

R/W

Default Destination GUID[3]: 0xFF

When MAC addressing is invoked, this register holds the most significant byte of the 32-bit destination

GUID. This register is used in conjunction with Destination GUID[2-0] registers to make up the module’s

32-bit destination GUID. For more information on the operation of addressing modes, please refer to the

Addressing Modes section of this document.

4.1.27. Destination GUID[2] (regDESTGUID[2])

regNVDESTGUID[2] (0x1E)

regDESTGUID[2] (0x69)

R/W

Default Destination GUID[2]: 0xFF

When MAC addressing is invoked, this register holds byte 2 of the 32-bit destination GUID. This register is

used in conjunction with Destination GUID[3] and Destination GUID[1-0] registers to make up the module’s

32-bit destination GUID. For more information on the operation of addressing modes, please refer to the

Addressing Modes section of this document.
