WI.232FHSS-25-R/ WI.232FHSS-250-R DATASHEET

Revision 1.1.0

4.2.2. Volatile Read-Only Registers

Volatile Read-Only Registers

Name

Address

Description

regEXCEPTION

0x79

Stores latest exception code

regLGPRSSI**

0x7B

Last Good Packet RSSI value

regIMMEDRSSI**

0x7C

Current RSSI value

** supported in 250(-R) module f/w v1.0.5 and newer

Table 24, Volatile Read-Only Register Summary

4.2.3. Non-Volatile Read-Only Registers

Non-Volatile Read-Only Registers

Name

Address

Description

regMYGUID[3]

0x34

Factory programmed GUID used in MAC Addressing Mode

regMYGUID[2]

0x35

Factory programmed GUID used in MAC Addressing Mode

regMYGUID[1]

0x36

Factory programmed GUID used in MAC Addressing Mode

regMYGUID[0]

0x37

Factory programmed GUID used in MAC Addressing Mode

regCUSTID[1]

0x39

Factory programmed customer ID, default 0xFF.

regCUSTID[0]

0x3A

Factory programmed customer ID, default 0xFF.

regRELEASENUM

0x78

Holds release number indicating h/w and f/w

Table 25, Non-Volatile Read-Only Register Summary
