WI.232FHSS-25-R/ WI.232FHSS-250-R DATASHEET

Revision 1.1.0

6.2. Detailed Electrical Specifications for WI.232FHSS-25-R

6.2.1. AC Specifications- Rx for WI.232FHSS-25-R

Parameter

Min

Typ

Max

Units

Notes

Receive Frequency- US

902.2

927.8

MHz

At antenna pin

Hop Sequences

26 channels each

Channel Spacing

750

kHz

Receiver Sensitivity

-100

dBm

152.34 kbit/ sec RF, 10

-3 BER

Receiver Sensitivity

-102

dBm

38.4 kbit/ sec RF, 10

-3 BER

Receiver Sensitivity

-105

dBm

9.6 kbit/ sec RF, 10

-3 BER

Input IP3

-40

dBm

Flo +1 MHz & Flo +1.945 MHz

Input Impedance

Ohms

No matching required

LO Leakage

-65

dBm

50 Ohm termination at ANT

Adjacent Channel Rejection

-48

dBc

Fc +/- 650 kHz

IF Bandwidth

600

kHz

Table 32, AC Specifications- Rx for WI.232FHSS-25-R

6.2.2. AC Specifications- Tx for WI.232FHSS-25-R

Parameter

Min

Typ

Max

Units

Notes

Transmit Frequency- US

902.2

927.8

MHz

Center Frequency Error

ppm

915 MHz @ 25

Frequency Deviation

160

kHz

Max. Output Power

dBm

915 MHz into 50 Ohm load

Output Impedance

Ohms

Carrier Phase Noise

TBD

dBc

Into 50 Ohm load

Harmonic Output

-50

dBc

Into 50 Ohm load

Table 33, AC Specifications- Tx for WI.232FHSS-25-R
