WI.232FHSS-25-R/ WI.232FHSS-250-R DATASHEET

Revision 1.1.0

3.1.4. Wi.232FHSS-250-R Pin Descriptions

No.

Description

No connect – reserved

UART Transmit output

Processing Packet signal

No connect – reserved

ISP pin / Wake from deep sleep/Module Reset

Reserved – ISP pin

No connect – reserved

Command Response indication – low when UART output is a command response

Exception Output, maskable. Cleared on exception read.

Ground

RSSI

Command Mode select – active low

Buffer Empty – high when input buffer is empty

N/C

UART Request To Send input – not currently implemented (reserved)

UART Clear To Send output – active low

UART Receive input

Ground

Antenna Port – 50 ohms

Ground

VCC

Table 8, WI.232FHSS-250-R Pin Descriptions

Legend

Signals that are used in this implementation

Signals used for in-system programming
