WI.232FHSS-25-R/ WI.232FHSS-250-R DATASHEET

Revision 1.1.0

4.1.22. User ID Mask[3] (regUSERIDMASK[3])

regNVUSERIDMASK[3] (0x17)

regUSERIDMASK[3] (0x62)

R/W

Default User ID Mask[3]: 0xFF

This register holds the most significant byte of the 32-bit extended-user address mask. When Extended

User addressing is invoked, this register is used in conjunction with User ID Mask[2-0] registers to make up

the module’s 32-bit extended-user address mask. For more information on the operation of addressing

modes, please refer to the Addressing Modes section of this document.

4.1.23. User ID Mask[2] (regUSERIDMASK[2])

regNVUSERIDMASK[2] (0x18)

regUSERIDMASK[2] (0x63)

R/W

Default User ID Mask[2]: 0xFF

This register holds byte 2 of the 32-bit extended-user address mask. When Extended User addressing is

invoked, this register is used in conjunction with User ID Mask[3] and User ID Mask[1-0] registers to make

up the module’s 32-bit extended-user address mask. For more information on the operation of addressing

modes, please refer to the Addressing Modes section of this document.

4.1.24. User ID Mask[1] (regUSERIDMASK[1])

regNVUSERIDMASK[1] (0x19)

regUSERIDMASK[1] (0x64)

R/W

Default User ID Mask[1]: 0xFF

When extended-user addressing is invoked, this register holds byte 1 of the 32-bit extended-user address

mask and is used in conjunction with User ID Mask[3-2] and User ID Mask[0] to form the complete address

mask; when user addressing is invoked, this register holds the most significant byte of the 16-bit user

address mask and is used in conjunction with the User ID Mask[0] register to form the complete address

mask. For more information on the operation of addressing modes, please refer to the Addressing Modes

section of this document.
