AB08X5-RTC Datasheet(PDF) 24 Page - Abracon Corporation |
|
|
|||||||||||||||||||||||||||||
AB08X5-RTC Datasheet(HTML) 24 Page - Abracon Corporation |
|
|
24 / 33 page  AB08X5 Real-Time Clock Family Date of Issue: October 16, 2014 3.0 x 3.0 mm Page 24 of 33 Abracon Drawing #453567 Revision: C Table 12: SPI AC Electrical Parameters SYMBOL PARAMETER VCC MIN TYP MAX UNIT fSCL SCL input clock frequency 1.7V–3.6V 0.01 2 MHz tLOW Low period of SCL clock 1.7V–3.6V 200 ns tHIGH High period of SCL clock 1.7V–3.6V 200 ns tRISE Rise time of all signals 1.7V–3.6V 1 µs tFALL Fall time of all signals 1.7V–3.6V 1 µs tSU:NCE nCE low setup time to SCL 1.7V–3.6V 200 ns tHD:NCE nCE hold time to SCL 1.7V–3.6V 200 ns tSU:CE nCE high setup time to SCL 1.7V–3.6V 200 ns tSU:SDI SDI setup time 1.7V–3.6V 40 ns tHD:SDI SDI hold time 1.7V–3.6V 50 ns tSU:SDO SDO output delay from SCL 1.7V–3.6V 150 ns tHD:SDO SDO output hold from SCL 1.7V–3.6V 0 ns tHZ SDO output Hi-Z from nCE 1.7V–3.6V 250 ns tBUF nCE high time before a new transmission 1.7V–3.6V 200 ns |
|
