AB08X5 Real-Time Clock Family

Date of Issue: October 16, 2014

3.0 x 3.0 mm

Page 29 of 33

Abracon Drawing #453567

Revision: C

8. Ordering Information

Table 16: Ordering Information

AB08X5 Orderable Part Numbers

Package

Temperature

Range

MSL Level(2)

P/N

Tape and Reel Qty

AB0805-T3

3000pcs/reel

Pb-Free(1) 16-Pin QFN 3 x

3 mm

-40 to +85 °C

AB0815-T3

3000pcs/reel

(1) Compliant and certified with the current RoHS requirements for all 6 substances, including the requirement that lead not

exceed 0.1% by weight in raw homogeneous materials. The package was designed to be soldered at high temperatures

(per reflow profile) and can be used in specified lead-free processes.

(2) Moisture Sensitivity Level rating according to the JEDEC J-STD-020D.1 industry standard classifications.
