Revision 1.0

Page 25 of 44

nRF24AP2-USB Product Specification

5.3.4

String descriptors

String descriptors provide information about the manufacturer, product and serial number for the

nRF24AP2-USB. These strings can be modified, see section 5.3.5 on page 25.

String Index 0 returns a list of supported languages.

Table 10. String index 0 (language identifier)

Table 11. String index 1 (manufacturer string)

Table 12. String index 2 (product string)

Table 13. String index 3 (serial number string)

5.3.5

Customize descriptors

The nRF24AP2-USB is programmed with default VID/PID values which allow it to function with the drivers

and libraries provided by ANT. However, it is possible to customize the nRF24AP2-USB. You can custom-

ize the following values and string descriptors:

•

Vendor ID (VID)

•

Product ID (PID)

•

Manufacturer string

•

Product string

•

Serial number

Field

Notes

Value

Description

bLength

0x04

bDescriptorType

0x03

STRING

wLANGID[0]

0x0409

English (US)

Field

Notes

Value

Description

bLength

0x30

bDescriptorType

0x03

STRING

bString

a. This field can be customized with your own manufacturer string

“Dynastream

Innovations”

Field

Notes

Value

Description

bLength

0x1E

bDescriptorType

0x03

STRING

bString

a. This field can be customized with your own product string

"ANT

USBStick2"

Field

Notes

Value

Description

bLength

0x2A

bDescriptorType

0x03

STRING

bString

a. This field can be customized with your own serial number

“123”
