Revision 1.0
Page 32 of 44
nRF24AP2-USB Product Specification
7
Operating conditions
Table 15. Operating conditions
Table 16. External circuitry specification
Symbol
Parameter (condition)
Notes Min.
Typ.
Max. Units
VBUS
Supply voltage
4.0
5
5.25
V
VDD
Alternative supply voltage
3.05
3.27
3.5
V
TEMP
Operating Temperature
-40
+27
+85
ºC
Symbol
Parameter (condition)
Notes
Min.
Typ.
Max.
Unit
16 MHz crystal
fNOM
Nominal frequency (parallel resonant)
16.000
MHz
fTOL
Frequency tolerance
a
a. Includes initial accuracy, stability over temperature, aging and frequency pulling due to incorrect load
capacitance
±50
ppm
CL
Load capacitance
9
16
pF
C0
Shunt capacitance
3
7
pF
ESR
Equivalent series resistance
50
100
Ω
PD
Drive level
100
µW
Bias resistor (IREF pin to GND)
Rref
Resistance
22
kΩ
Rrefacc
Tolerance
1
%
