background image
Revision 1.0
Page 35 of 44
nRF24AP2-USB Product Specification
Table 19. Serial timing
8.2
DC Electrical characteristics
Table 20. DC characteristics
Table 21.Digital inputs/outputs
Symbol
Parameter (condition)
Notes
Min.
Typ.
Max.
Units
tSuspend Idle to suspend time
3.25
ms
tReset
Power on reset time, software reset,
and reset pin
2.0
ms
tResponse-
Max
The time the nRF24AP2-USB uses to
respond to an input command
1.0
ms
Symbol
Parameter (condition)
Notes
Min.
Typ.
Max.
Units
On-chip voltage regulators
VDD
Output voltage
a
a. Also valid for VDD input voltage
3.05
3.27
3.5
V
IVDD
External load current
2
mA
Symbol
Parameter (condition)
Notes
Min.
Typ.
Max.
Units
VIH
Input high voltage
0.7
⋅VDD
VDD
V
VIL
Input low voltage
VSS
0.3·VDD
V
