Protecta Plus

Order Codes

P R OT EC TA P LUS – O R D ER CO D E S

Pack contents: Row type boards

• Fixings

• DIN rail / mounting plate

• RAL7035 textured finish

Description

Order codes

Protecta Plus - Row Type N-Bar 9

EPP-N-09

Protecta Plus - Row Type N-Bar 13

EPP-N-13

Protecta Plus - Row Type N-Bar 17

EPP-N-17

Protecta Plus - Row Type N-Bar 21

EPP-N-21

Protecta Plus - Row Type E-Bar 9

EPP-PE-09

Protecta Plus - Row Type E-Bar 13

EPP-PE-13

Protecta Plus - Row Type E-Bar 17

EPP-PE-17

Protecta Plus - Row Type E-Bar 21

EPP-PE-21

—

Additional N/PE for side extension boxes

No. of modules

No. of

rows

Sided

width

Dimension

Height

Order codes

4way DB

590

EPP-R2036

8way DB

730

EPP-R3054

12way DB

870

EPP-R4072

16way DB

1050

EPP-R5090

108

20way DB

1220

EPP-R6108

126

24way DB

1360

EPP-R7126

—

Row type extension boxes

Description

Order codes

Protecta Plus - Top Shroud

EPP-TC

Protecta Plus Mains TS - 4 Way

EPP-MTCO4

Protecta Plus Mains TS - 8 Way

EPP-MTCO8

Protecta Plus Mains TS - 12 Way

EPP-MTC12

Protecta Plus Mains TS - 16 Way

EPP-MTC16

Protecta Plus Mains TS - 20 Way

EPP-MTC20

Protecta Plus Mains TS - 20 Way

EPP-MTC24

—

Terminal cover
