AT89C51AC3-RDTIM Datasheet(PDF) 34 Page - ATMEL Corporation |
|
|
|||||||||||||||||||||||||||||
AT89C51AC3-RDTIM Datasheet(HTML) 34 Page - ATMEL Corporation |
|
|
34 / 140 page  34 AT89C51AC3 4383D–8051–02/08 Registers Table 10. PCON Register PCON (S87:h) Power configuration Register Reset Value= XXXX 0000b 7 6 5 4 3 2 1 0 - - - - GF1 GF0 PD IDL Bit Number Bit Mnemonic Description 7-4 - Reserved The value read from these bits is indeterminate. Do not set these bits. 3 GF1 General Purpose flag 1 One use is to indicate whether an interrupt occurred during normal operation or during Idle mode. 2 GF0 General Purpose flag 0 One use is to indicate whether an interrupt occurred during normal operation or during Idle mode. 1 PD Power-Down Mode bit Cleared by hardware when an interrupt or reset occurs. Set to activate the Power-Down mode. If IDL and PD are both set, PD takes precedence. 0 IDL Idle Mode bit Cleared by hardware when an interrupt or reset occurs. Set to activate the Idle mode. If IDL and PD are both set, PD takes precedence. |
|
