ADM1026

http://onsemi.com

Table 65. REGISTER 33H, AIN3 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

AIN3 Value

This register contains the measured value of the AIN3 analog input channel.

Table 66. REGISTER 34H, AIN4 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

AIN4 Value

This register contains the measured value of the AIN4 analog input channel.

Table 67. REGISTER 35H, AIN5 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

AIN5 Value

This register contains the measured value of the AIN5 analog input channel.

Table 68. REGISTER 36H, AIN6 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

AIN6 Value

This register contains the measured value of the AIN6 analog input channel.

Table 69. REGISTER 37H, AIN7 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

AIN7 Value

This register contains the measured value of the AIN7 analog input channel.

Table 70. REGISTER 38H, FAN0 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN0 Value

This register contains the measured value of the FAN0 tach input channel.

Table 71. REGISTER 39H, FAN1 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN1 Value

This register contains the measured value of the FAN1 tach input channel.

Table 72. REGISTER 3AH, FAN2 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN2 Value

This register contains the measured value of the FAN2 tach input channel.

Table 73. REGISTER 3BH, FAN3 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN3 Value

This register contains the measured value of the FAN3 tach input channel.

Table 74. REGISTER 3CH, FAN4 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN4 Value

This register contains the measured value of the FAN4 tach input channel.

Table 75. REGISTER 3DH, FAN5 MEASURED VALUE (POWER-ON DEFAULT, 00H)

Bit

Name

R/W

Description

7–0

FAN5 Value

This register contains the measured value of the FAN5 tach input channel.
