DocID4578 Rev 24

35/42

M24C32-W M24C32-R M24C32-F M24C32-X M24C32-DF

Package mechanical data

Figure 17. TSSOP8 – 8-lead thin shrink small outline, package outline

1. Drawing is not to scale.

Table 22. TSSOP8 – 8-lead thin shrink small outline, package mechanical data

Symbol

millimeters

inches(1)

1. Values in inches are converted from mm and rounded to four decimal digits.

Typ.

Min.

Max.

Typ.

Min.

Max.

–

1.200

–

0.0472

–

0.050

0.150

–

0.0020

0.0059

1.000

0.800

1.050

0.0394

0.0315

0.0413

–

0.190

0.300

–

0.0075

0.0118

–

0.090

0.200

–

0.0035

0.0079

–

0.100

–

0.0039

3.000

2.900

3.100

0.1181

0.1142

0.1220

0.650

–

0.0256

–

6.400

6.200

6.600

0.2520

0.2441

0.2598

4.400

4.300

4.500

0.1732

0.1693

0.1772

0.600

0.450

0.750

0.0236

0.0177

0.0295

1.000

–

0.0394

–

0°

8°

–

0°

8°
