AT89C51AC3-RDTIM Datasheet(PDF) 125 Page - ATMEL Corporation |
|
|
|||||||||||||||||||||||||||||
AT89C51AC3-RDTIM Datasheet(HTML) 125 Page - ATMEL Corporation |
|
|
125 / 143 page  125 AT89C51AC3 4383B–8051–01/05 External Program Memory Characteristics Table 73. Symbol Description Table 74. AC Parameters for a Fix Clock (F = 40 MHz) Symbol Parameter T Oscillator clock period TLHLL ALE pulse width TAVLL Address Valid to ALE TLLAX Address Hold After ALE TLLIV ALE to Valid Instruction In TLLPL ALE to PSEN TPLPH PSEN Pulse Width TPLIV PSEN to Valid Instruction In TPXIX Input Instruction Hold After PSEN TPXIZ Input Instruction Float After PSEN TAVIV Address to Valid Instruction In TPLAZ PSEN Low to Address Float Symbol Min Max Units T25 ns TLHLL 40 ns TAVLL 10 ns TLLAX 10 ns TLLIV 70 ns TLLPL 15 ns TPLPH 55 ns TPLIV 35 ns TPXIX 0ns TPXIZ 18 ns TAVIV 85 ns TPLAZ 10 ns |
|
