from VIN when output regulators are enabled. This adds power
consumption of approximately 15 mW at minimum VIN. There-
fore the sum of power dissipations for all output regulators is
approximately 280 mW.
The total power dissipation of the IC is then the sum of the boost
stage and the linear regulators: 0.30 W + 0.28 W = 0.58 W. This
corresponds to a temperature rise of just 21.5°C. Therefore, at
the highest ambient temperature of 85°C, the estimated junction
temperature is 106.5°C under the above worst-case conditions.
