38B5 Group User’s Manual
APPLICATION
2-153
2.11 Clock generating circuit
Fig. 2.11.4 Setting of relevant registers
CPU mode register (address 003B16)
0
CPUM
00 0
Main clock: High-speed mode (f(XIN)) (Note 1)
00
CPU mode register (address 003B16)
0
CPUM
00 1
Port XC: XCIN-XCOUT oscillation function
00
CPU mode register (address 003B16)
1
CPUM
00 1
Internal system clock: Low-speed mode (f(XCIN))
00
CPU mode register (address 003B16)
1
CPUM
01 1
Main clock f(XIN): Stopped
00
(Note 2)
(Note 2)
(Note 2)
Notes 1: This setting is necessary only when selecting the high-
speed mode.
2: When selecting the middle-speed mode, bit 6 is “1”.



Html Pages
