39 / 52 page  DA9080 High Current, Highly Configurable System PMIC with Four Bucks and One LDO Datasheet Revision 1.2 08-Feb-2022 CFR0011-120-00 39 of 51 © 2022 Renesas Electronics Bit Type Field Name Description Reset Value Description 0x0 CH4 Buck no OV event 0x1 CH4 Buck OV event [3] RW1C BUCK3_OV_EVENT Indicates a CH3 Buck over-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH3 Buck no OV event 0x1 CH3 Buck OV event 0x0 [2] RW1C BUCK2_OV_EVENT Indicates a CH2 Buck over-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH2 Buck no OV event 0x1 CH2 Buck OV event 0x0 [1] RW1C BUCK1_OV_EVENT Indicates a CH1 Buck over-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH1 Buck no OV event 0x1 CH1 Buck OV event 0x0 Table 21: PMC_CH_UV (0x0003) Bit Type Field Name Description Reset [4] RW1C BUCK4_UV_EVENT Indicates a CH4 Buck under-voltage (UV) event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH4 Buck no UV event 0x1 CH4 Buck UV event 0x0 [3] RW1C BUCK3_UV_EVENT Indicates a CH3 Buck under-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH3 Buck no UV event 0x1 CH3 Buck UV event 0x0 [2] RW1C BUCK2_UV_EVENT Indicates a CH2 Buck under-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH2 Buck no UV event 0x1 CH2 Buck UV event 0x0 [1] RW1C BUCK1_UV_EVENT Indicates a CH1 Buck under-voltage event. Clear by a POR or writing 1 via I2C. Value Description 0x0 CH1 Buck no UV event 0x0 |
|
