DA9080
High Current, Highly Configurable System
PMIC with Four Bucks and One LDO
Datasheet
Revision 1.2
08-Feb-2022
CFR0011-120-00
45 of 51
© 2022 Renesas Electronics
Bit
Type
Field Name
Description
Reset
buck output voltage has completed ramping down
to 0 V.
Value
Description
0x0
Disabled - NOT recommended
0x1
Enabled
[3]
RW
BUCK3_DISCHARGE
CH3 Buck discharge resistor control. Connects
resistor to ground when channel is shut down.
When disabled, excessive charge may be left on
output capacitors (NOT recommended).
When enabled the resister will be connected after
the buck output voltage has completed ramping
down to 0 V.
Value
Description
0x0
Disabled - NOT recommended
0x1
Enabled
0x1
[2]
RW
BUCK2_DISCHARGE
CH2 Buck discharge resistor control. Connects
resistor to ground when channel is shut down.
When disabled, excessive charge may be left on
output capacitors (NOT recommended). When
enabled the resister will be connected after the
buck output voltage has completed ramping down
to 0 V.
Value
Description
0x0
Disabled - NOT recommended
0x1
Enabled
0x1
[1]
RW
BUCK1_DISCHARGE
CH1 Buck discharge resistor control. Connects
resistor to ground when channel is shut down.
When disabled, excessive charge may be left on
output capacitors (NOT recommended). When
enabled the resister will be connected after the
buck output voltage has completed ramping down
to 0 V.
Value
Description
0x0
Disabled - NOT recommended
0x1
Enabled
0x1
[0]
RW
LDO_DISCHARGE
LDO discharge resistor control. Connects resistor
to ground when channel is shut down. When
disabled, excessive charge may be left on output
capacitors (NOT recommended).
Value
Description
0x0
Disabled - NOT recommended
0x1
Enabled
0x1
Table 34: PMC_TEMP (0x0011)
Bit
Type
Field Name
Description
Reset
[7:0]
RW
TEMP
Indicates ADC TEMP value.
Temperature, T (ºC) = -1.97*CODE + 349
0x0
