25 / 52 page  DA9080 High Current, Highly Configurable System PMIC with Four Bucks and One LDO Datasheet Revision 1.2 08-Feb-2022 CFR0011-120-00 25 of 51 © 2022 Renesas Electronics Once the output voltage discharge ramp is finished, and after a suitable delay, the slot is completed and the sequencer moves to slot three and repeats the process. When all slots are complete, the power-down sequence is finished. The startup and shutdown sequencers may be triggered by register write. The FORCE_DISABLE register bit will shut down the regulators if written high whilst the chip is enabled. When using this register care should be taken that the regulators are not also disabled by writing their individual enable registers: The FORCE DISABLE register is located in the same register bank as the individual regulator enable bits (EN1/2/3/4/L) If the regulator enables are set low when FORCE_DISABLE is used then the regulators will not restart when FORCE_DISABLE is cleared. |
|
