DA9080
High Current, Highly Configurable System
PMIC with Four Bucks and One LDO
Datasheet
Revision 1.2
08-Feb-2022
CFR0011-120-00
9 of 51
© 2022 Renesas Electronics
5
Characteristics
5.1
Absolute Maximum Ratings
Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to
the device. These are stress ratings only, so functional operation of the device at these or any other
conditions beyond those indicated in the operational sections of the specification are not implied.
Exposure to Absolute Maximum Rating conditions for extended periods may affect device reliability.
Table 3: Absolute Maximum Ratings
Parameter
Description
Conditions
Min
Max
Unit
TSTG
Storage temperature
-60
150
°C
VSYS
System supply voltage
Referenced to AGND
-0.3
6
V
VPIN
All other pins
Referenced to AGND
-0.3
6
V
5.2
Electrostatic Discharge Ratings
Table 4: Electrostatic Discharge Ratings
Parameter
Description
Conditions
Value
Unit
VESD_HBM
Maximum ESD protection
Human body model (HBM)
All exposed pins
2
kV
VESD_CDM
Maximum ESD protection
Charged device model (CDM)
0.5
kV
5.3
Recommended Operating Conditions
Table 5: Recommended Operating Conditions
Parameter
Description
Conditions
Min
Typ
Max
Unit
TA
Operating ambient
temperature
-40
85
°C
TJ
Operating junction
temperature
-40
125
°C
VSYS
Input supply voltage
4
5.5
V
VPIN
Voltage on all other pins
-0.3
VIN+0.
3
V
