background image
DA9080
High Current, Highly Configurable System
PMIC with Four Bucks and One LDO
Datasheet
Revision 1.2
08-Feb-2022
CFR0011-120-00
43 of 51
© 2022 Renesas Electronics
Bit
Type
Field Name
Description
Reset
[3:2]
RW
BUCK2_GRP
Assign CH2 Buck to a power-up / power-down
sequencing slot.
Value
Description
0x0
CH2 Buck is assigned to slot 1
0x1
CH2 Buck is assigned to slot 2
0x2
CH2 Buck is assigned to slot 3
0x3
CH2 Buck is assigned to slot 4
0x2
[1:0]
RW
BUCK1_GRP
Assign CH1 Buck to a power-up / power-down
sequencing slot.
Value
Description
0x0
CH1 Buck is assigned to slot 1
0x1
CH1 Buck is assigned to slot 2
0x2
CH1 Buck is assigned to slot 3
0x3
CH1 Buck is assigned to slot 4
0x1
Table 30: PMC_LDO_SEQ_GRP (0x000D)
Bit
Type
Field Name
Description
Reset
[1:0]
RW
LDO_GRP
Assign LDO to a power-up / power-down
sequencing slot.
Value
Description
0x0
LDO is assigned to slot 1
0x1
LDO is assigned to slot 2
0x2
LDO is assigned to slot 3
0x3
LDO is assigned to slot 4
0x0
Table 31: PMC_PG1 (0x000E)
Bit
Type
Field Name
Description
Reset
[4]
RW
BUCK4_PG1
Assign CH4 Buck to PG1 monitor group.
Value
Description
0x0
CH4 Buck is not assigned to PG1 group
0x1
CH4 Buck is assigned to PG1 group
0x0
[3]
RW
BUCK3_PG1
Assign CH3 Buck to PG1 monitor group.
Value
Description
0x0
CH3 Buck is not assigned to PG1 group
0x1
CH3 Buck is assigned to PG1 group
0x0
[2]
RW
BUCK2_PG1
Assign CH2 Buck to PG1 monitor group.
Value
Description
0x0
CH2 Buck is not assigned to PG1 group
0x1
CH2 Buck is assigned to PG1 group
0x1
