background image
DA9080
High Current, Highly Configurable System
PMIC with Four Bucks and One LDO
Datasheet
Revision 1.2
08-Feb-2022
CFR0011-120-00
23 of 51
© 2022 Renesas Electronics
Parameter
Description
Conditions
Min
Typ
Max
Unit
tSETUP_START
Start condition setup time
0.26
μs
tHOLD_START
Start condition hold time
0.26
μs
tSETUP_STOP
Stop condition setup time
0.26
μs
tDATA
Data valid time
0.45
μs
tDATA_ACK
Data valid acknowledge time
0.45
μs
tSETUP_DATA
Data setup time
50
ns
tHOLD_DATA
Data hold time
0
ns
tSPIKE
Spike suppression pulse
width
0
50
ns
5.5.10
Digital I/O Characteristics
Table 16: Digital I/O Electrical Characteristics
Parameter
Description
Conditions
Min
Typ
Max
Unit
Electrical Performance
VIH_SCL_SDA
Input high voltage, SCL, SDA
1.2
V
VIL_SCL_SDA
Input low voltage, SCL, SDA
0.4
V
VOL_PG1
PG1 output low voltage,
POR
IOUT = 3 mA
0.4
V
VOL_PG2
PG2 output low voltage,
POR
IOUT = 3 mA
0.4
V
VOL_SDA
Output low voltage, SDA
IOUT = 3 mA
0.4
V
VIH_EN
Input high voltage, CH1SEL
1.2
V
VIL_EN
Input low voltage, CH1SEL
0.4
V
tENH_DEB
EN Pin rising debounce time
100
ms
tENL_DEB
EN Pin falling debounce time
10
μs
