background image
DA9080
High Current, Highly Configurable System
PMIC with Four Bucks and One LDO
Datasheet
Revision 1.2
08-Feb-2022
CFR0011-120-00
22 of 51
© 2022 Renesas Electronics
Parameter
Description
Conditions
Min
Typ
Max
Unit
IVSYS_OP
Total current of VSYS pin
OPERATING mode
EN = H and
FORCE_DISABLE = L
CH<x> = All ON
Buck: ON with no switching
and no load
LDO: ON with no load
ADC: ON
IO: Non I2C communication
500
600
μA
IPVINx_OP
Total current from PVIN1,
PVIN2, PVIN3, and PVIN4
pins
OPERATING mode
EN = H and
FORCE_DISABLE = L
CH<x> = All ON
Buck: ON with no switching
and no load
0
10
μA
IVDDIO
Total current from VDDIO pin
No I2C communication
VSYS = 5 V
VDDIO = 3.3 V
SCL = SDA = H
0.16
1
μA
ILDOIN_OP
Total current of LDOIN pin
OPERATING mode
EN = H and
FORCE_DISABLE = L
CH<x> = All ON
LDO: ON with no load
2.7
10
μA
5.5.9
I2C Characteristics
Table 15: I2C Electrical Characteristics
Parameter
Description
Conditions
Min
Typ
Max
Unit
Electrical Performance
Standard/Fast/Fast+ Mode
tBUS
Bus free time between a
STOP and START condition
0.5
μs
CBUS
Bus line capacitive load
150
pF
fSCL
SCL clock frequency
1000
kHz
tLO_SCL
SCL low time
0.5
μs
tHI_SCL
SCL high time
0.26
μs
tRISE
SCL and SDA rise time.
Requirement for input.
1000
ns
tFALL
SCL and SDA fall time.
Requirement for input.
300
ns
