Appendix

Parts List

Each switch provides an accessory kit that contains parts that are required to install the switch into

a four-post rack. Two-post rack mount parts are available through your sales representative. The

following sections list the installation parts provided by the accessory kit.

C.1

Parts Used in All Configurations

Quantity

Description

One for each AC power supply

module supplied with switch.

Power cables: 14 AWG, C19-C20.

One for each DC power supply

module supplied with switch.

DC Adapter (Arista part number CON-00581; part number

G10TBL2021100211HR; Figure 36: DC Adapter ), Terminal

Block, M4 Lug.

One

RJ-45 Patch Panel Cables, 2 meters.

One

RJ-45 to DB9 Adapter Cable, 2 meters.

Warning: All provided power cables are for use only with Arista products.

Figure 36: DC Adapter

C.2

Four-Post Rack Mount Parts

Quantity

Description

Mounting Ears

Left shelf
