AT89C51ID2

4289A–8051–09/03

Table 31. CCAPnL Registers (n = 0-4)

CCAP0L - PCA Module 0 Compare/Capture Control Register Low (0EAh)

CCAP1L - PCA Module 1 Compare/Capture Control Register Low (0EBh)

CCAP2L - PCA Module 2 Compare/Capture Control Register Low (0ECh)

CCAP3L - PCA Module 3 Compare/Capture Control Register Low (0EDh)

CCAP4L - PCA Module 4 Compare/Capture Control Register Low (0EEh)

Reset Value = 0000 0000b

Not bit addressable

Table 32. CH Register

CH - PCA Counter Register High (0F9h)

Reset Value = 0000 0000b

Not bit addressable

Table 33. CL Register

CL - PCA Counter Register Low (0E9h)

Reset Value = 0000 0000b

Not bit addressable

765

43210

--------

Bit

Number

Bit

Mnemonic

Description

7-0

PCA Module n Compare/Capture Control

CCAPnL Value

7654

3210

--------

Bit

Number

Bit

Mnemonic

Description

7-0

PCA counter

CH Value

7654

3210

--------

Bit

Number

Bit

Mnemonic

Description

7-0

PCA Counter

CL Value
