T89C51AC2
TL2 (S:CCh)
Timer 2 Low Byte Register
Reset Value = 0000 0000b
Not bit addressable
Figure 58. TL2 Register
RCAP2H (S:CBh)
Timer 2 Reload/Capture High Byte Register
Reset Value = 0000 0000b
Not bit addressable
Figure 59. RCAP2H Register
RCAP2L (S:CAh)
Timer 2 Reload/Capture Low Byte Register
Reset Value = 0000 0000b
Not bit addressable
Figure 60. RCAP2L Register
7
6
5
4
3
2
1
0
--------
Bit Number Bit Mnemonic
Description
7-0
Low Byte of Timer 2.
7
6
5
4
3
2
1
0
--------
Bit Number Bit Mnemonic
Description
7-0
High Byte of Timer 2 Reload/Capture.
7
6
5
4
3
2
1
0
--------
Bit Number Bit Mnemonic
Description
7-0
Low Byte of Timer 2 Reload/Capture.
