42 / 117 page  42 Draft.A - March 30, 2001 Preview - Confidential T89C51AC2 10.2. Flash Programming and Erasure There are three methods of programming the Flash memory: • The Atmel bootloader located in FM1 is activated by the application. Low level API routines (located in FM1) to program FM0 will be used. The interface used for serial downloading to FM0 is the UART. API can be called also by user’s bootloader located in FM0 at [SBV]00h. • A further method exist in activating the Atmel boot loader by hardware activation. • The FM0 can be programed also by the parallel mode using a programmer. Figure 27. Flash Memory Mapping F800h 7FFFh 32 Kbytes Flash memory 2 Kbytes IAP bootloader FM0 FM1 Custom Boot Loader [SBV]00h FFFFh FM1 mapped between FFFF and F800 when API called 0000h |
|
