98 / 117 page  98 Draft.A - March 30, 2001 Preview - Confidential T89C51AC2 IPL0 (S:B8h) Interrupt Enable Register Reset Value: x000 0000b bit addressable Figure 89. IPL0 Register 7 6 5 4 3 2 1 0 - PPC PT2 PS PT1 PX1 PT0 PX0 Bit Number Bit Mnemonic Description 7- Reserved The value read from this bit is indeterminate. Do not set this bit. 6 PPC EWC Counter Interrupt Priority bit Refer to PPCH for priority level 5 PT2 Timer 2 overflow interrupt Priority bit Refer to PT2H for priority level. 4PS Serial port Priority bit Refer to PSH for priority level. 3 PT1 Timer 1 overflow interrupt Priority bit Refer to PT1H for priority level. 2 PX1 External interrupt 1 Priority bit Refer to PX1H for priority level. 1 PT0 Timer 0 overflow interrupt Priority bit Refer to PT0H for priority level. 0 PX0 External interrupt 0 Priority bit Refer to PX0H for priority level. |
|
