WM8946ECS/R Datasheet(PDF) 6 Page - Wolfson Microelectronics plc |
|
|
|||||||||||||||||||||||||||||
WM8946ECS/R Datasheet(HTML) 6 Page - Wolfson Microelectronics plc |
|
|
6 / 175 page  WM8946 Production Data w PD, July 2012, Rev 4.3 6 PIN CONFIGURATION The WM8946 is supplied in a 36-pin CSP format. The pin configuration is illustrated below, showing the top-down view from above the chip. SDA BCLK IN2L AUX1 CS/ GPIO2 LINEOUTL IN1R VBIN AUX2 IN1L/ DMICDAT IN2R VBREFR MICBIAS VMIDC LDOVOUT SPKVDD DNC DNC GND LDOVDD SPKOUTL SCLK SDOUT/ GPIO4 DACDAT LRCLK DBVDD CIFMODE /GPIO3 GPIO1 DCVDD DNC DNC ADCDAT SPKOUTR LINEOUTR VBOUT MCLK 16 5 4 3 2 A F E D C B ORDERING INFORMATION ORDER CODE TEMPERATURE RANGE PACKAGE MOISTURE SENSITIVITY LEVEL PEAK SOLDERING TEMPERATURE WM8946ECS/R -40 C to +85C 36-ball W-CSP (Pb-free, tape and reel) MSL1 260 oC Note: Reel quantity = 5000 |
|
