WM8946ECS/R Datasheet(PDF) 155 Page - Wolfson Microelectronics plc |
|
|
|||||||||||||||||||||||||||||
WM8946ECS/R Datasheet(HTML) 155 Page - Wolfson Microelectronics plc |
|
|
155 / 175 page  Production Data WM8946 w PD, July 2012, Rev 4.3 155 Register 86h SE2_5BEQ_L10G REGISTER ADDRESS BIT LABEL DEFAULT DESCRIPTION REFER TO R135 (87h) SE2_5BEQ_ L32G 12:8 SE2_5BEQ_L3 G[4:0] 0_1100 Filter coefficients for Signal Enhancement 2 (SE2) left channel 5-band EQ filter Gain 00000 : -12dB 00001 : -12dB 00010 : -10dB 00011 : -9dB …. (1dB steps) 11000 : 12dB 11001 to 11111 : Reserved 4:0 SE2_5BEQ_L2 G[4:0] 0_1100 Filter coefficients for Signal Enhancement 2 (SE2) left channel 5-band EQ filter Gain 00000 : -12dB 00001 : -12dB 00010 : -10dB 00011 : -9dB …. (1dB steps) 11000 : 12dB 11001 to 11111 : Reserved Register 87h SE2_5BEQ_L32G REGISTER ADDRESS BIT LABEL DEFAULT DESCRIPTION REFER TO R136 (88h) SE2_5BEQ_ L4G 4:0 SE2_5BEQ_L4 G[4:0] 0_1100 Filter coefficients for Signal Enhancement 2 (SE2) left channel 5-band EQ filter Gain 00000 : -12dB 00001 : -12dB 00010 : -10dB 00011 : -9dB …. (1dB steps) 11000 : 12dB 11001 to 11111 : Reserved Register 88h SE2_5BEQ_L4G REGISTER ADDRESS BIT LABEL DEFAULT DESCRIPTION REFER TO R137 (89h) SE2_5BEQ_ L0P 15:0 SE2_5BEQ_L0 P[15:0] 0000_0000 _1101_100 0 Filter coefficients for Signal Enhancement 2 (SE2) left channel 5-band EQ filter Register 89h SE2_5BEQ_L0P REGISTER ADDRESS BIT LABEL DEFAULT DESCRIPTION REFER TO R138 (8Ah) SE2_5BEQ_ L0A 15:0 SE2_5BEQ_L0 A[15:0] 0000_1111 _1100_101 0 Filter coefficients for Signal Enhancement 2 (SE2) left channel 5-band EQ filter Register 8Ah SE2_5BEQ_L0A |
|
